Product Overview
The High Speed Cylindrical UV Cans Printer delivers exceptional print quality with 360-degree rotary printing capabilities, designed for industrial manufacturing applications.
Key Features
- High Precision: 3.5pl droplet size provides optimal balance between throughput and print quality, suitable for various applications
- High Resolution: Multiple inkjet schemes adapt to different printing materials with accurate colors, distinct layers, and uniform transitions
- Intelligent Maintenance: Automatic nozzle flashing and moisture retention during non-working states prevents ink curing blockages
Technical Specifications
Model: CF-2510 (Duplex)
| Equipment Specifications |
Details |
| Nozzle Selection |
Ricoh GEN 5i |
| Print Size |
235cm × 63.2cm |
| Printing Height |
0-15cm (Customizable) |
| Equipment Size |
412cm × 159cm × 144cm |
| Equipment Weight |
860kg |
| Printing Software |
Photoprint / PrintFactory |
| Ink Type |
LED Environmental Protection UV Ink |
| Ink Colors |
W+CMYK+Varnish |
| Maximum Power |
3000W |
| Nozzle Specifications |
Effective Orifice: 1280 |
| Ink Drop Volume |
3.5PL |
| Nozzle Length |
27MM |
| Single Nozzle Color |
4 |
| Rated Voltage |
240V 50/60HZ |
Company Profile
Guangzhou Skydeekenutek Co., Ltd. specializes in distribution and wholesale of UV printers, including single-pass UV printers, UV flatbed printers, UV mesh belt printers, banner printers, and crystal label printers. Our 2500 m² factory in Panyu, Guangzhou employs over 10 R&D staff and 150 workers with ISO certification and strict quality control. We support OEM and ODM services with over 10 years of UV printer manufacturing experience, exporting to France, Germany, Vietnam, India and other countries. All products carry CE and RoHS certification.
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: Do I need white ink and varnish ink?
White ink enables high-quality graphics on various materials including acrylic boards and backlit films, and serves as a primer for non-white substrates. Varnish enhances print brightness and extends UV ink fade resistance.
Q2: What materials can UV flatbed printers print on?
All flatbed media including PP/PVC boards, KT boards, acrylic, plexiglass, metal, tiles, phone cases, and wood boards. UV printing eliminates coating requirements and prevents fading and blistering, making it ideal for rigid identification boards, packaging, and custom decoration markets.
Q3: Which languages does the RIP installation interface support?
Korean, German, French, Finnish, Dutch, Portuguese, Japanese, Spanish, Italian, English, Simplified Chinese, and Traditional Chinese.
Q4: How is the after-sales service?
Our experienced technical team provides comprehensive support, including operational training until full proficiency is achieved. International technical assistance and on-site testing/repair services are available.
Q5: Regarding printer maintenance
Daily ink purging is recommended when starting the printer. For extended non-use periods exceeding 10 days, nozzle cleaning with specialized fluid and moisture retention is essential.
Q6: Are you a factory or a foreign trade company?
We are a manufacturing factory, enabling us to offer competitive pricing and high-quality services directly.
